Grid Membrane(Individual&Continuous Pack)
Grid Membrane-Specifications
Grid Membrane-Features
- Quality control begins with the QA of raw materials and maintained during and post-membrane casting process through regular sample testing intervals that includes microbial testing and particle counts.
- Gridded lines do not inhibit colony growth.
- All membrane filters comply with ISO 7704.
- MCE membranes is a mixture of cellulose nitrate and cellulose acetate which allows effective retention with high-flow rates and optimal colony growth.
- Each shipment includes COA ( Certificate of Analysis) or Quality Certificate .
Grid Membrane-Quality Control
- Bacterial Challenge: LRV>7（ATCC19146, ATCC14756,ASTM bacterial challenge test )for each lot of 0.2um and 0.45um products.
- Bacterial Endotoxin : < 0.25 EU/mL or < 2.15EU/device (LAL) for each lot of devices.
- Biosafety: Meets USP<88>Biological Reactivity test for Class VI Plastics.
- Recovery of Fecal Coliform: ≥90 %
- Traceable: All QC data is traceable for each lot from raw material to finished product.
- Reliably: Each lot of products are tested for seal and membrane integrity.
- ISO 9001 Quality Standard
Grid Membrane-Comparison of Bacterial recovery Rate against competitors
Grid Membrane-Comparison of Flow Rate against competitors
High Flowrate MCE membrane provides short filtration times for water, beer, wine, juice and other beverages saving time especially for multiple samples
Grid Membrane-Excellent Performance of Grids
Orientfiltr High Performance MCE membrane uses microbiological – “friendly” ink which promotes growth on grids to maximize recovery
Grid Membrane-Applications
Applications:
“Membrane Filtration Technique”
-Food Hygiene, water analysis method
- Colony counting (Microbial enumeration)
- General Microscopy
- Particulate counting and analysis
Industries:
- Bottled Water
- Food & Beverage (Beer, Wine, carbonated drinks, etc.)
- Environmental
- Cosmetics
- Pharmaceutical
Grid Membrane-Core Competitions
